Climate

How to Install a Window Air Conditioner

Measure the window and check the outlet first. Install the support, secure the AC and sash, seal the gaps, then test for movement and indoor leaks.

A white window air conditioner sits in a bedroom window with a level on top, and a black-handled screwdriver and a small screw rest on the sill beside it.

Start with the window and the support

The quick read
  • Measure the opening, inspect the sill and match the outlet to the AC before lifting.
  • Prepare the mounting kit and install any required weight support first.
  • Seat the unit, fasten it and restrain the sash before letting go. Seal the gaps afterward.
  • Run it only when it is stable, positioned for drainage and plugged directly into a grounded wall outlet matching its rating.

We’d start with fit and support, because a cabinet that fits between the jambs can still lack room for its panels or bracket. The support carries the weight; the mounting hardware keeps the AC from shifting, and the seals close the remaining gaps. This is for window-mounted units; portable vent hoses and through-wall installations use different mounts.

How the mounting parts differ
InstallationSupport and restraintWindow and seal
Standard sash unitSeat the bottom rail and fasten the cabinet; confirm it stays still.Lower and lock the sash, fasten side panels, then seal the gaps.
U-shaped unitSecure its bracket, seat the AC and engage the anti-tip arms; confirm no rocking.Lower the sash into the channel and fit the shaped seals.
Slide-out-chassis unitFasten the empty cabinet and supports; reinsert and retain the chassis.Lock the sash and seal the panel edges.
Slider or casement unitFasten the sill platform and cabinet restraint; confirm the cabinet cannot shift.Capture the rigid filler in its retainers and seal the remaining opening.
Friedrich slide-out storm-window exampleFasten a sound riser to the sill; confirm the cabinet clears the storm frame.Set the riser top about 1/2 inch above the frame; confirm drainage position.
A white window air conditioner sits in a bedroom window with a level on top, and a black-handled screwdriver and a small screw rest on the sill beside it.

Will your AC fit this window and outlet?

A conventional window AC with a sash-mounted kit is made for a single-hung or double-hung window, where the lower sash moves up. Match the plug to the receptacle, voltage and circuit rating before lifting (GE Appliances’ plug and outlet guide (opens in a new tab)). Keep the unit on the floor while you measure. Before lifting, choose another window if the AC would block a fire escape window or other required exit.

  1. Raise the lower sash and measure the clear width between the jambs and the open height from sill to sash. Compare both with the minimum and maximum window dimensions for your unit and kit. Measure again even if another AC fit there.
  2. Measure the usable sill depth and how far the sash can lower onto the unit or into its channel. Lay out the side panels and support to see whether they fit that opening. Look outside for a storm-window frame, wall or screen that would interfere with the bracket or block the rear and side louvers.
  3. Read the unit’s weight and inspect the sill and frame. Choose any separate bracket by a load rating above that weight and by its fit with the sill and wall. A soft, loose or damaged frame needs repair before it carries an AC.
  4. Read the electrical rating and compare it with the receptacle, circuit and plug. A 115-volt unit may need a 15-amp supply; a 208/230-volt unit may need 20 amps. Confirm the rating on yours, and make sure its own cord reaches a grounded wall outlet.

How do you support and secure a standard window AC?

These steps are for a fixed-cabinet unit whose rails and side panels attach before the whole AC goes into a vertical-sash window. Gather the supplied hardware, a tape measure, pencil, screwdriver, scissors and level. If screws go into the window, a 1/8-inch bit is a common pilot-hole size; confirm the bit size and fastening points in the AC’s installation instructions.

  1. Open the window, remove the screen if it obstructs the mount, and mark the center of the clear opening. Fit the supplied top rail with all its fasteners, slide the left and right curtains into their tracks, and attach the adhesive sash seal where the kit places it. Each panel should move without coming free.
  2. If the unit or window needs a separate support, choose one that fits the sill and is rated above the AC’s weight. On a sill-and-wall bracket, seat its inner contact on the sound sill, bring its outer foot firmly against the wall, and fasten or clamp it. Press the installed support from indoors; it must not shift before the AC goes on it.
StopAn unsecured AC can shift or fall and injure someone below. Keep hold of it until the weight support, cabinet fasteners and sash restraint are engaged; foam and the sash alone cannot carry it.
  1. Arrange a second person for a bulky, heavy or high lift. With the support ready, bring the AC to the centered opening and keep control of it throughout the next steps.
  2. Set the bottom rail or guide against the sill in its intended position. Lower the sash behind the top rail while your helper still holds the AC. If the rails do not meet the sill and sash properly, lift the unit back out and correct the fit.
  3. Set the unit’s required drainage position before fastening it. Some designs sit level; others need a small outward drop, commonly about 1/4 inch. Confirm the angle for yours in its installation instructions before you lock the brackets.
  4. Fasten the cabinet or supplied sill brackets into sound material. Extend each side-panel frame to the window and fasten it at its mounting points. The cabinet should stay centered and still when gently tested from indoors.
  5. Fit the supplied sash lock, commonly held by one screw, so the lower sash cannot rise and release the AC. For a vinyl frame or rental that bars drilling, use a complete no-drill mounting system only if its weight support, cabinet restraint and mechanical sash restraint all work in that window. A separate no-drill bracket does not replace cabinet screws required by the AC. If those parts cannot be secured, remove the AC.
  6. Seal the side-panel edges and press the supplied foam into the gap between the upper and lower sashes. Look along the full length of each seal for daylight.

What changes for a U-shaped unit?

A U-shaped AC takes its weight on its supplied bracket, with the sash closing into the channel and shaped fillers sealing the gaps. For example, on Midea U-shaped units, Midea’s installation guide (opens in a new tab) places the bracket’s horizontal bar and extension arms on the room side, its support feet against the outside wall, and its anti-tip arms in the vertical window tracks.

  1. Center and secure the supplied bracket before lifting. Bring both exterior support feet against the wall, lock its support pins and test the bracket for movement.
  2. With help if the lift is awkward, place the unit fully on its support. Secure its side arms; where the kit has anti-tip arms, extend them into the vertical window tracks and fasten them. The unit should sit on the bracket without rocking.
  3. Lower the sash into the U channel, secure the window and fit the shaped fillers and foam. Gaps should close without forcing the sash against the AC.

If the chassis slides out

Use this sequence only for an AC designed with a removable chassis. The secured empty cabinet and its supports carry the weight; retaining hardware keeps the chassis seated inside it.

  1. With power disconnected, remove the front, retaining screws and chassis in the unit’s stated order. Keep the original screws for reassembly. The empty cabinet should be light enough to position without pushing on its controls or finned coils.
  2. Fit the cabinet’s panels and supports, then mount and fasten the empty cabinet and sash. Test that the cabinet cannot move before lifting the chassis back toward it.
  3. Slide the chassis fully to the back of the cabinet, replace its required retaining screws or lock, and refit the front and filter. If it will not seat fully or the hardware does not engage, leave it off and correct the obstruction before use.

What if the window slides sideways or has a storm frame?

A horizontal slider opens sideways; a casement window swings on hinges. Neither opening safely takes a conventional vertical-sash kit turned on its side. Use a window AC and mounting kit designed for that opening, and close the remaining space with the panels and seals specified by the kit.

  1. Measure the clear opening against a unit and kit made for that slider or casement window. Check for sound structure for the kit’s specified support and cabinet restraint, and for a rigid filler if the kit uses one. If the moving casement sash or crank blocks the specified mounting parts, stop before lifting.
  2. For a kit with a sill platform, fasten the platform beside the jamb, bring its exterior support against the wall, and adjust it for the unit’s drainage position. Seat the AC on it and fasten the cabinet or safety restraint. Trim the rigid filler to the remaining opening, capture it in its retainers, secure the moving window and seal the gaps. The platform must bear the weight while the restraint prevents the cabinet from shifting.
  3. If a raised storm-window frame blocks a sash-window unit, fasten a sound riser along the interior sill where the unit permits one. Recheck cabinet clearance, secure seating and drainage position. A loose shim is not a support.

How can you tell it is secure and ready to run?

From indoors, gently test the cabinet for rocking without pushing it outward. Confirm that the bracket, cabinet fasteners, chassis or anti-tip parts and sash restraint are engaged. The sash must not rise unexpectedly, the side and sash gaps should be sealed, and nothing outside should cover the rear or side air paths.

StopA mismatched plug, extension cord, power strip or adapter can overheat or create an electrical hazard. Use the AC’s own undamaged cord directly in a dry, grounded wall outlet that matches its plug, voltage and circuit rating.
  1. Look over the cord and plug, then plug the AC directly into the matching outlet. If its protective plug has TEST and RESET buttons, press TEST and then RESET as the cord instructions direct. It should trip and reset normally.
  2. Switch the unit on and select a setting that calls for cooling. Confirm that air flows from the front and turns cool while the cabinet remains still. Keep the outdoor vents clear throughout the run.
  3. Watch the indoor side and sill for water. Condensate may remain in the outdoor pan or drip outdoors because some units use that water around the condenser. No water should drip into the room.

If the unit does not start, confirm the plug is seated, the controls call for cooling and the outlet works with another small appliance. Then look at the house breaker or fuse. A protective plug that will not trip or reset, or a breaker that trips again, ends the startup test.

If it shifts, leaks indoors or still will not run

StopA sagging AC can fall, and water leaking indoors can cause shock or fire. Keep it off until the mount and drainage are secure; drilling a new hole in the base pan can damage the unit and bypass its intended water handling. Unplug the AC at a dry outlet before touching a wet mount. If the plug or outlet is wet, do not touch it.
  1. If the cabinet moves or sags, support it with help and examine the bracket, sill fasteners, anti-tip parts and sash lock. Refasten only into sound material and test again from indoors. Remove the AC if the window cannot hold or restrain it.
  2. If water drips indoors, compare the mounted position with the unit’s required level or outward drop using a level. Correct the support or sill seating. Use an existing drain fitting only when the unit provides one.
  3. Run the securely mounted AC again. Success means the cabinet stays still and condensate remains in its intended pan or goes outdoors, with no indoor dripping. If it still leaks, will not start, has a hot or damaged plug, or trips the breaker again, leave it off.

When the window cannot carry or restrain the unit, contact a qualified window AC installer or window repair professional. A bracket-supported installation of one owner-supplied conventional AC in a sound vertical-sash window runs $180 to $700, including a $30 to $100 bracket and 2 to 4 labor hours at $75 to $150 an hour.

For an outlet or circuit mismatch, call a licensed electrician; for a failed protective cord or unit fault, contact the maker’s support or authorized service. Give them the unit’s model, weight and electrical rating, the opening measurements, window type and floor, the support kit, whether drilling is allowed, and whether you saw movement, indoor water, no startup, a hot plug or a tripped breaker.

Keep the installation working

If the window is bumped or the unit seems to move, test the cabinet gently from indoors and confirm the sash lock and support still hold. A dirty filter can contribute to indoor dripping; clean the AC filter when it gets dirty. Keep the outdoor air paths clear as part of air conditioner maintenance.

Questions about power, water and installation cost

Can I use an extension cord if the outlet is too far away?

No. An adapter cannot change an outlet’s voltage or circuit capacity. Choose a window with an outlet the AC’s cord reaches, or have a correctly rated outlet installed.

Should I drill a drain hole in the AC?

No. Drilling can damage the pan or internal parts. Indoor dripping calls for a mounting-position check; use a supplied drain fitting if the unit provides one.

How much does it cost to have a window AC installed?

Labor for one owner-supplied AC in a suitable window runs $150 to $600, built from 2 to 4 hours at $75 to $150 an hour; the AC is extra. A bracket-supported job has the range given above. Old-unit removal adds $50 to $200; custom filler, storm-window work and electrical work add separate charges. For an unusual window, give the installer the unit’s weight and type, window type and floor, support and filler needs, and electrical requirements.
